Especificações
Working height | 31.8 m |
Platform height | 29.8 m |
Horizontal outreach | 21.6 m |
Up and over clearance | 11.35 m |
Below ground reach | 5.5 m |
Lift capacity | 250 kg (2 pers.) |
Platform size | 2.44 x 0.91 m |
Length - stowed | 11.7 m |
Width | 2.53 m |
Height - stowed | 2.8 m |
Storage / transport length | 8.9 m |
Storage / transport height | 3.75 m |
Vertical jib rotation | 140° (+ 70 / - 70) |
Platform rotation | 180° (+ 90 / - 90) |
Turntable rotation | 360° continuous |
Tailswing | 3.3 m |
Wheelbase | 3.5 m |
Ground clearance | 38 cm |
Tilt | 5 ° |
Drive speed | 0.5 - 5 km/h |
Maximum wind speed rating | 60 km/h |
Gradeability | 40 % |
Tires - foam-filled | 445 / 65-22.5 |
Turning radius - outside axle extended | 5.74 m |
Power source | Deutz, 55 kW, Turbo (Stage 5 in EU) ; Perkins, 62.5 kW, Turbo (Stage 3A in NRC) |
Weight | 20 100 kg |
Width - with extended axles | 3.3 m |
